產品特點
- 緊湊型功率計表頭
投射電容式觸摸屏，多點觸控技術
兼容30多種功率能量探頭 詳細介紹
觸屏功率能量計表頭，多點觸控技術
PM400與S120C光電二極管探頭(下方有售)和TSP-TH溫度探頭緊湊型功率計表頭
投射電容式觸摸屏，多點觸控技術
兼容30多種功率能量探頭(下方有售)
輸入端口，可用于第三方和自定義探頭
4 GB內存
USB 2.0接口，通過PC進行控制
Thorlabs的PM400功率計表頭兼容30多種功率能量探頭(下方有售)。與這些探頭一起使用時，該表頭會自動檢測和讀出存儲在探頭接頭里的校準信息，并將這些數據與用戶設定的測量波長結合，提供已校準的功率或能量測量。該表頭也可與第三方或自定義探頭一起使用，只需滿足規格標簽中列出的兼容性要求即可。
Thorlabs提供PM400重新校準服務(查看下方型號CAL-PM1)。另外，如果您有對應的探頭需要重新校準，您可以將探頭與PM400一起送來校準，無需額外的費用。訂購信息請查看本頁底部。
規格
Specifications Compatible Detectors Thorlabs' C-Series Photodiode, Thermal Power, Thermal Position & Power, and Pyroelectric Sensors (Except Item # ES408C)
Photodiodes up to 5 mA, Thermopiles up to 1 V, and Pyroelectric Detectors up to 100 V
See Table Below for Additional DetailsDisplay Type 4.3" TFT, WQVGA, 400 x 272 Pixels, 16 Bit Color Viewing Area 95 mm x 54 mm Update Rate (Max) 10 Hz Numerical, 25 Hz Analog Simulation Format Numerical, Bar Graph, Trend Graph, Statistics, and Simulated Analog Needle Backlight LED, Adjustable Features Projected Capacitive Touchscreen and Buttons, Support Stand, Rubberized Outside,
2 x M3 Threaded Inserts for Mounting on Back SideAnalog Output Connector 3.5 mm Mono Audio (2P) Jack, Adapter to BNC Included Signal Amplified Input Signal - Not Corrected Voltage Range 0 to 2 V Accuracy ±3% Bandwidth Up to 100 kHz, Dependent on Sensor and Settings Auxiliary Input/Output Connector 2 x 7 Pins, 0.1" Socket, Top Side Function 4 x GPIO
2 x 10 bit ADC for External Temperature, Relative Humidity Sensor
+3.3 V, +/- 2.5 V (100 mA Max)Temperature Sensor Internal to C-Series Optical Sensora Temperature Sensor Type Thermistor Temperature Measurement Range -10 °C to 80 °C External Temperature Sensor Supported Temperature Sensor Thermistor NTC 0.1 - 100 kΩ, B-Value 1000 - 9999 K Temperature Measurement Range -10 °C to 80 °C (with TSP-TH) Connector 2.5 mm Stereo Audio (3P) Jack Sound Type Internal Speaker Function Laser Tuning Support, Console Function Support Memory Type NAND Flash Size 4 GB Interfaces Type USB 2.0 Connector Mini-B USB Power Management Battery LiPo 3.7 V 2600 mAh Charger Built In; Charging Current: 0.5 / 1 A Power Connector Mini USB General Operating Temperature Rangeb 0 to 40 °C Storage Temperature Range -40 to 70 °C Dimensions 136 mm x 96 mm x 29 mm Weight 0.35 kg 許多Thorlabs兼容C系列的光功率和能量探頭都有內置的溫度探頭。
非冷凝
Sensor Compatibility Sensor Type Photodiode Power Sensors Thermal Power Sensors
Thermal Position & Power SensorsPyroelectric Energy Sensorsa Input Type Current Voltage Voltage Connector (on PM400) Female DB9 Units W, dBm, W/cm2, A W, dBm, W/cm2, V J, J/cm2, W, W/cm2, V Measurement Ranges 6 Decades;
50 nA, 500 nA, 5 μA, 50 μA, 500 μA, 5 mA
Ranges Selectable in W
(Sensor Dependent)9 Ranges:
2, 4, 10, 20, 40, 100, 200, 400, 1000 mV
Ranges Selectable in W
(Sensor Dependent)4 Ranges:
200 mV, 2V, 20 V, 100 V
Ranges Selectable in J
(Sensor Dependent)Display Resolution 1 pA / Responsivity Value (A/W) 1 μV / Responsivity Value (V/W) 100 μV / Responsivity Value (V/J) AD Converter 16 bit Accuracy ±0.2% Full Scale (5 μA - 5 mA)
±0.5% Full Scale (50 nA)±0.5% Full Scale (10 mV - 1 V)
±1% Full Scale (2 mV)±0.5% Full Scale Bandwidth DC - 100 kHz, Dependent on Sensor and Settings N/A Trigger Threshold N/A N/A 3% - 90% Full Scale Time Constant
Correction RangeN/A 1 s - 30 s N/A Repetition Rate (Max) N/A N/A 3 kHz Wavelength Correction nm, A/W (Sensor Dependent) nm, V/W (Sensor Dependent) nm, V/J (Sensor Dependent) Beam Area Setting Diameter 1/e2 or Rectangular XY 由于PM400表頭只能支持*高3 kHz重復頻率，因此它們不應與可探測高達10 kHz重復頻率的ES408C探頭一起使用。
所有技術數據在23 ± 5 °C、相對濕度45 ± 15%(非冷凝)時you效。
